Accucold offers innovative solutions to vaccine storage with the STACKMED2 stackable refrigerator-freezer combination series.
Sized just under 24" wide, the FFAR10-FS24LSTACKMED2 combines our full-sized FFAR10MED2 auto defrost all-refrigerator with the compact FS24LMED2 all-freezer in one slim footprint. Made in Europe, the FFAR10MED2 offers 10.1 cu.ft. of storage, with fan-forced cooling and adjustable wire shelves to ensure an even temperature distribution. The FS24LMED2 freezer utilizes static manual defrost cooling.
Both units feature front-located control panels equipped with digital thermostats and NIST calibrated thermometers with high/low temperature alarms. Calibration is done in our ISO/IEC certified laboratory. The buffered temperature probes are encased in a glycol-filled bottle and secured inside the center shelf to best simulate the temperature of other stored contents, resulting in the utmost accuracy for temperature reporting. We include a pre-installed 3/8" probe hole for users who wish to install additional monitoring equipment in the rear of both units. Additional features include front locks and hospital grade cords. Products in the MED2 series come with a two year warranty on parts and labor and a five year warranty on the compressor.
All Accucold STACKMED2 units ship in three boxes and require some minor assembly upon delivery. Additional stacked combinations can be created by ordering virtually any two units with our StackRack. These units can also be customized with a variety of refrigeration options, including NIST calibrated thermometers, USB data loggers, open door alarms, and much more. To create a custom combination, contact our sales team at 718-893-3900.
*NOTE: Thermostats come pre-set for Celsius. If you prefer Fahrenheit, add complimentary option DTMEDF or let your sales representative know upon order.
Features
Features
Allows you to create a full refrigerator-freezer with independent controls in a slim-fitting footprint
Designed to comply with the most current guidelines for vaccine storage
10.1 cu.ft. auto defrost all-refrigerator with digital controls, internal fan, flat door liner, and adjustable shelving
Compact manual defrost all-freezer with digital thermostat and wire shelving
Unit ships in three boxes for customer to install the StackRack on the bottom refrigerator/freezer and place and secure the other unit on top
Rear-mounted 3/8" access port in both units allows users to install their own monitoring equipment
Audible alarm sounds if the interior temperature rises or falls out of set range
Alarms include continuous NIST calibrated display of the current interior and high/low temperature, and can be switched from Celsius to Fahrenheit at the touch of a button
Thermometer probe is encased in a glycol-filled bottle and stored in a fixed box on the center shelf. This is the ideal way to produce temperature readings closest to stored contents, as recommended by the CDC and VFC's guidelines
Secure three-pronged cord for added unit safety (both units)
Both models include locks for added security, with two keys included for each unit
StackRack ships with anti-tip bracket for easy aftermarket installation
Designed to ensure a sufficiently insulated interior
Quality door gaskets ensure a tight seal for energy savings and improved performance
ETL and ETL-C listed for North American sales
Standard unit ships with a right hand door swing. For a left hand door swing, add option LHD upon order (due to its construction, this door is not reversible in the field)
This unit comes with a two-year limited warranty on parts & labor and five-year warranty on the compressor
Environmentally friendly design with no ozone-damaging chemicals
Specifications
Specifications
| Capacity | 11.5 cu.ft. (326 L) |
| Door | White |
| Cabinet | White |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Voltage/Frequency | 115 V AC/60 Hz |
| Parts & Labor Warranty | 2 Years |
| Compressor Warranty | 5 Years |
| UPC | 761101058702 |
| Refrigerator-Freezer | |
| Door Swing | RHD |
| Reversible | Factory Reversible |
| Adjustable Shelves | Yes |
| Interior Light | Yes |
| Refrigerator - Capacity | 10.1 cu.ft |
| Refrigerator - Shelf Type | Wire |
| Refrigerator - Shelf Qty | 4 |
| Refrigerator - Temperature Range | 2 C to 8 C |
| Refrigerator - Refrigerant Type | R134a |
| Refrigerator - Refrigerant Amount | 3.0 oz. |
| Freezer - Capacity | 1.4 cu.ft |
| Freezer - Shelf Type | Wire |
| Freezer - Shelf Qty | 1 |
| Thermostat Type | Digital |
| Fan Type | Interior |
| Freezer - Temperature Range | -20 to -15 C |
| Freezer - Refrigerant Type | R600a |
| Freezer - Refrigerant Amount | 0.8 oz. |
Dimensions & Weight
Dimensions & Weight
| Height of Cabinet | 78.75" (200 cm) |
| Width | 24.0" (61 cm) |
| Depth | 23.5" (60 cm) |
| Depth with Handle | 24.75" (63 cm) |
| Depth with door at 90° | 45.5" (116 cm) |
| Voltage/Frequency | 115 V AC/60 Hz |
| Shipping Weight | 195.0 lbs. (88 kg) |
| Freezer - Interior Height | 14.38" (37 cm) |
| Freezer - Interior Width | 13.5" (34 cm) |
| Freezer - Interior Depth | 13.25" (34 cm) |
Downloads & Manual
Downloads & Manual
| Brochure | |
|---|---|
| Msds Information | |
| Use & Care | |
| Use & Care |
